BOD Testing
APHA 5210-B EPA 405.1
SRI3 SHEL LAB BOD Refrigerated Incubator 2.4
Cu. Ft. (68 L)
The SRI3 space-saving low temperature incubator is ideal for small volume workloads and meets APHA specifications for Biochemical Oxygen Demand (B.O.D.) analysis.
SHEL LAB Low Temperature Incubators are ideal for testing B.O.D. of sewage and waste water, as well as other low and room temperature applications. Features include:
· Microprocessor Control
· P.I.D. Temperature_Control
· LED Display of Setpoint and Chamber Temperature
· High Limit Thermostat
· Interior Electrical Outlet
· Fan Assisted/Forced-Air Circulation
· Hermetically Sealed Compressor
BOD Refrigerated Incubator
· Programmable logic microprocessor controller with LCD Control · Panel with message center
· 4x20 character LCD display
· Continuous product temperature Hi/Lo alarms, audible and visual
· Programmable ramp soak feature
· 2 levels of user password protection (set points and parameters)
· Will store up to (334) 300 Ml BOD bottles
· Warranties: 12 months parts and labor (US and Canada), 12 months parts (International)
· Programmable logic microprocessor controller with LCD control panel with message center
· 4 x 20 character LCD display
· Continuous product temperature Hi/Lo alarms, audible and visual
· Programmable ramp soak feature
· 2 levels of user password protection (set points and parameters)
· 100 event alarm logging including Date/Time Stamp and product temperatures. Stored in non volatile flash memory
· Integrated Hi/Lo alarm tests
· Power failure alarm
· Remote alarm contacts
· Proportional control and capacity output
· White interior, exterior, door and handle
· 4 wire shelves (1st and 3rd shelves are adjustable)
· Streamlined refrigeration design optimizes air flow and temperature uniformity
· Selectable on demand auto defrost
· Key lock door
· 2 adjustable leveling legs
· Interior LED light
· 1” diameter access port with plug
· 6 full width door storage compartments
· Complete cabinet is foamed-in-place with CFC free high density polyurethane foam insulation
· Warranties: 12 months parts and labor (US and Canada), 12 months parts (International)
· Crated Height (in)(cm): 86-1/2 (220)
· Crated Width (in)(cm): 42 (107)
· Crated Depth (in)(cm): 42 (107)
· Interior Height (in)(cm): 56-3/4 (144)
· Interior Width (in)(cm): 26-7/8 (68)
· Interior Depth (in)(cm): 23-3/4 (60)
· Overall Height (in)(cm): 82-1/2 (210)
· Overall Width (in)(cm): 34 (86)
· Overall Depth (in)(cm): 31-3/4 (81)
· Number of Shelves: 4 + 6 Door Compartments
· Shelf Area (SqFt)(Sqm): 18.6 (1.7) · Voltage Description: 115/60/1
· NEMA Plug Configuration: 5-15P
· NEMA Receptacle: 5-15R
· Total Amp Draw: 5.0
MultiLab 4010 (1, 2 3)
Laboratory instrument for DO/BOD, pH, ORP, conductivity and ion activity measurement. EPA approved for drinking water and wastewater compliance reporting.
Connect digital IDS sensors to the MultiLab 4010-2 for the measurement of DO/BOD, pH, ORP, and conductivity in any combination. Ion selective electrodes (ISEs) can also be connected to the instrument.
Instrument Only. Cables, probes/sensors, and accessories sold separately.
The YSI MultiLab line includes the 4010-1 (single channel), 4010-2 (dual channel) and 4010-3 (three channel) instruments providing easy to use and calibrate menu-driven operation ideal for the laboratory.
All MultiLab instruments can accurately measure pH, ORP, conductivity, and DO/BOD. ISEs can also be connected to two and three channel instruments.
Features of the MultiLab line:
· Input for pH, ORP, DO/BOD, or conductivity sensors
· ISEs with BNC connection can be connected to the MultiLab 4010-2 and 4010-3 with an adapter (108132Y) that converts
one digital input to an analog BNC input (i.e. only one ISE can be connected)
· Data storage - 500 data sets in manual mode and 5,000 (MultiLab 4010-1) or 10,000 (MultiLab 4010-2 and 4010-3) data sets in automatic logging mode
· Large, easy to read graphic display
· Color screen and antibacterial keypad on MultiLab 4010-2 and 4010-3 instruments
· Intelligent, digital sensors - plug and play connectivity
· GLP traceability (sensors store serial # and calibration data)
· USB connectivity to manage data; USB cable included
· PC software included for easy data transfer
· Durable electrode stand included
· 3-year warranty
Intelligent Digital Sensors (IDS)
The IDS sensors automatically store their unique serial number and calibration data. In addition, they also digitally process the measurement signal. The sensors can be moved from instrument to instrument and maintain their calibration data and transmit this information to the new instrument.
Plug and play connectivity with each instrument
IDS senors store their own unique ID with serial number and calibration data
Digital sensor recognition, processing and data transfer
Includes self-stirring BOD, pH, ORP and conductivity sensors
BOD probe uses optical dissolved oxygen technology and includes a guarded sensor tip
EPA Approved Methodology
All MultiLab instruments can be used with the IDS OBOD probe for wastewater compliance reporting of BOD and CBOD. Available IDS pH and conductivity sensors can also be used for drinking water and wastewater compliance reporting.
By using the available BNC adapter and the corresponding ISE, the MultiLab 4010-2 and 4010-3 can be used for compliance reporting of Ammonia (wastewater),Bromide (wastewater), Chloride(wastewater), Cyanide (wastewater and drinking water), Fluoride (wastewater and drinking water), Nitrate (wastewater and drinking water), Potassium (wastewater), and Sulfide (wastewater).
Continuous Measurement Control (CMC)
The CMC function displays continual monitoring of the sensor's measuring range. The range is represented with a bar and calibration points are shown as vertical lines at the cal point. A moving cursor shows the current measured value and indicates if the measurement is within the calibrated range.
Quality Sensor Control (QSC)
The QSC is a system to monitor the condition of the pH electrode. An initial calibration is performed and, afterwards, the sensor status is monitored and graphically displayed over time.
Glucose-Glutamic Acid Solution
(Refrigeration not required)
Buffers & Solutions
BOD Seeds
Polyseed, an EPA accepted, commercially available
B.O.D. seed inoculum, is a broad spectrum of specialized bacteria blended specifically to be used as a seed population for the Biochemical Oxygen Demand test as conducted according to Standard Methods for the Examination of Water and Wastewater.
Extreme Savings Opportunities
Cu. Ft. (68 L)The SRI3 space-saving low temperature incubator is ideal for small volume workloads and meets APHA specifications for Biochemical Oxygen Demand (B.O.D.) analysis.
SHEL LAB Low Temperature Incubators are ideal for testing B.O.D. of sewage and waste water, as well as other low and room temperature applications. Features include:
· Microprocessor Control
· P.I.D. Temperature_Control
· LED Display of Setpoint and Chamber Temperature
· High Limit Thermostat
· Interior Electrical Outlet
· Fan Assisted/Forced-Air Circulation
· Hermetically Sealed Compressor
Click Here for Features & Specifications
SKU:SRI3
Units are equipped with a hermetically-sealed compressor, a circuit breaker to protect from electrical overload, and an easy-to-clean fully insulated chamber that is corrosion-resistant. Gentle, continuous forced-air circulation ensures temperature uniformity and reproducible test conditions. Each unit also includes an independent over temperature safety controller, two shelves (adjustable in two inch increments), and a one amp interior outlet to allow the use of shakers, stirrers, roller bottles or other apparatus. This unit has a steel exterior with welded seams and corners and a double-coated, baked enamel finish. It is supplied with adjustable leveling feet and a condensation drip tray.
· Interior Outlet:115V-1/230V-2
· Shelving:2 Supplied
· Temperature Uniformity:+/- 0.5°C at 20°C
· Temperature Range:0°C to 45°C (at 20°C ambient)
· Exterior Dimensions WxDxH in. (cm):24 x 21 x 33.8 (61 x 53.4 x 85.8)
· Interior Dimensions WxDxH in. (cm):16 x 12 x 21.5 (40.6 x 30.4 x 54.6)
· Capacity:2.4 Cu.Ft. (68 L)
· Capacity of Standard B.O.D. Bottles:62
· Maximum Energy Consumption (W):575/805
All specifications are determined by using average values on standard equipment at an ambient temperature of (22 ± 3)°C and line voltages within +/-10% of unit type (115V/230V). Temperature specifications follow DIN 12880 methodology. We reserve the right to change specifications at any time.
Units are equipped with a hermetically-sealed compressor, a circuit breaker to protect from electrical overload, and an easy-to-clean fully insulated chamber that is corrosion-resistant. Gentle, continuous forced-air circulation ensures temperature uniformity and reproducible test conditions. Each unit also includes an independent over temperature safety controller, two shelves (adjustable in two inch increments), and a one amp interior outlet to allow the use of shakers, stirrers, roller bottles or other apparatus. This unit has a steel exterior with welded seams and corners and a double-coated, baked enamel finish. It is supplied with adjustable leveling feet and a condensation drip tray.
· Interior Outlet:115V-1/230V-2
· Shelving:2 Supplied
· Temperature Uniformity:+/- 0.5°C at 20°C
· Temperature Range:0°C to 45°C (at 20°C ambient)
· Exterior Dimensions WxDxH in. (cm):24 x 21 x 33.8 (61 x 53.4 x 85.8)
· Interior Dimensions WxDxH in. (cm):16 x 12 x 21.5 (40.6 x 30.4 x 54.6)
· Capacity:2.4 Cu.Ft. (68 L)
· Capacity of Standard B.O.D. Bottles:62
· Maximum Energy Consumption (W):575/805
All specifications are determined by using average values on standard equipment at an ambient temperature of (22 ± 3)°C and line voltages within +/-10% of unit type (115V/230V). Temperature specifications follow DIN 12880 methodology. We reserve the right to change specifications at any time.
| Part No. | Description | QTY |
|---|---|---|
| I426-056 | 3.2 Cu. Ft | 1/ea |
BOD Refrigerated Incubator
· Programmable logic microprocessor controller with LCD Control · Panel with message center
· 4x20 character LCD display
· Continuous product temperature Hi/Lo alarms, audible and visual
· Programmable ramp soak feature
· 2 levels of user password protection (set points and parameters)
· Will store up to (334) 300 Ml BOD bottles
· Warranties: 12 months parts and labor (US and Canada), 12 months parts (International)
Click Here for Features & Specifications
Features
· Operating temperature: -10°C to 50°C· Programmable logic microprocessor controller with LCD control panel with message center
· 4 x 20 character LCD display
· Continuous product temperature Hi/Lo alarms, audible and visual
· Programmable ramp soak feature
· 2 levels of user password protection (set points and parameters)
· 100 event alarm logging including Date/Time Stamp and product temperatures. Stored in non volatile flash memory
· Integrated Hi/Lo alarm tests
· Power failure alarm
· Remote alarm contacts
· Proportional control and capacity output
· White interior, exterior, door and handle
· 4 wire shelves (1st and 3rd shelves are adjustable)
· Streamlined refrigeration design optimizes air flow and temperature uniformity
· Selectable on demand auto defrost
· Key lock door
· 2 adjustable leveling legs
· Interior LED light
· 1” diameter access port with plug
· 6 full width door storage compartments
· Complete cabinet is foamed-in-place with CFC free high density polyurethane foam insulation
· Warranties: 12 months parts and labor (US and Canada), 12 months parts (International)
Specifications
· Crated Weight (lbs)(kg): 380 (172)· Crated Height (in)(cm): 86-1/2 (220)
· Crated Width (in)(cm): 42 (107)
· Crated Depth (in)(cm): 42 (107)
· Interior Height (in)(cm): 56-3/4 (144)
· Interior Width (in)(cm): 26-7/8 (68)
· Interior Depth (in)(cm): 23-3/4 (60)
· Overall Height (in)(cm): 82-1/2 (210)
· Overall Width (in)(cm): 34 (86)
· Overall Depth (in)(cm): 31-3/4 (81)
· Number of Shelves: 4 + 6 Door Compartments
· Shelf Area (SqFt)(Sqm): 18.6 (1.7) · Voltage Description: 115/60/1
· NEMA Plug Configuration: 5-15P
· NEMA Receptacle: 5-15R
· Total Amp Draw: 5.0
| Part No. | Description | QTY |
|---|---|---|
| R220-013 | 20 Cu. Ft | 1/ea |
MultiLab 4010 (1, 2 3)
Laboratory instrument for DO/BOD, pH, ORP, conductivity and ion activity measurement. EPA approved for drinking water and wastewater compliance reporting.
Connect digital IDS sensors to the MultiLab 4010-2 for the measurement of DO/BOD, pH, ORP, and conductivity in any combination. Ion selective electrodes (ISEs) can also be connected to the instrument.
Instrument Only. Cables, probes/sensors, and accessories sold separately.
Click Here for Features & Specifications
The YSI MultiLab line includes the 4010-1 (single channel), 4010-2 (dual channel) and 4010-3 (three channel) instruments providing easy to use and calibrate menu-driven operation ideal for the laboratory.
All MultiLab instruments can accurately measure pH, ORP, conductivity, and DO/BOD. ISEs can also be connected to two and three channel instruments.
Features of the MultiLab line:
· Input for pH, ORP, DO/BOD, or conductivity sensors
· ISEs with BNC connection can be connected to the MultiLab 4010-2 and 4010-3 with an adapter (108132Y) that converts
one digital input to an analog BNC input (i.e. only one ISE can be connected)
· Data storage - 500 data sets in manual mode and 5,000 (MultiLab 4010-1) or 10,000 (MultiLab 4010-2 and 4010-3) data sets in automatic logging mode
· Large, easy to read graphic display
· Color screen and antibacterial keypad on MultiLab 4010-2 and 4010-3 instruments
· Intelligent, digital sensors - plug and play connectivity
· GLP traceability (sensors store serial # and calibration data)
· USB connectivity to manage data; USB cable included
· PC software included for easy data transfer
· Durable electrode stand included
· 3-year warranty
Intelligent Digital Sensors (IDS)
The IDS sensors automatically store their unique serial number and calibration data. In addition, they also digitally process the measurement signal. The sensors can be moved from instrument to instrument and maintain their calibration data and transmit this information to the new instrument.
Plug and play connectivity with each instrument
IDS senors store their own unique ID with serial number and calibration data
Digital sensor recognition, processing and data transfer
Includes self-stirring BOD, pH, ORP and conductivity sensors
BOD probe uses optical dissolved oxygen technology and includes a guarded sensor tip
EPA Approved Methodology
All MultiLab instruments can be used with the IDS OBOD probe for wastewater compliance reporting of BOD and CBOD. Available IDS pH and conductivity sensors can also be used for drinking water and wastewater compliance reporting.
By using the available BNC adapter and the corresponding ISE, the MultiLab 4010-2 and 4010-3 can be used for compliance reporting of Ammonia (wastewater),Bromide (wastewater), Chloride(wastewater), Cyanide (wastewater and drinking water), Fluoride (wastewater and drinking water), Nitrate (wastewater and drinking water), Potassium (wastewater), and Sulfide (wastewater).
Continuous Measurement Control (CMC)
The CMC function displays continual monitoring of the sensor's measuring range. The range is represented with a bar and calibration points are shown as vertical lines at the cal point. A moving cursor shows the current measured value and indicates if the measurement is within the calibrated range.
Quality Sensor Control (QSC)
The QSC is a system to monitor the condition of the pH electrode. An initial calibration is performed and, afterwards, the sensor status is monitored and graphically displayed over time.
| Autostable | Yes |
|---|---|
| Benchtop | Yes |
| Buffer Recognition | Yes |
| Certifications | CE, cETLus |
| Connectivity / Communications | Mini USB, USB-A |
| Data Management | 500 data sets in manual mode and 10,000 data sets in automatic mode |
| Desktop Software Compatible | BOD Analyst Pro desktop software to automatically calculate BOD values |
| Digital / Digital Sensors | Yes |
| Display | Large, easy to read graphic color displays |
| Equipment used with | Multilab IDS probes and accessories |
| GLP Compliance | Yes |
| Graphic Display | Large, easy to read graphic color displays |
| Keypad | Antibacterial |
| Logging Capabilities | Yes |
| Measurement Method / Channels | 2 Measurement Channels |
| Measurement Range | pH - 0.000 to 14.000 (+/-0.004), Conductivity - 10 µS/cm to 2,000 mS/cm +0.5% of value (301710Y), .01µS/cm to 200 µS/cm +0.5% of value (301720Y), TDS - 0 to 100ºC (32 to 212ºF), Dissolved Oxygen - 0 to 50 mgL; 0 to 500% air saturation, Salinity - 0.0 to 70.0 ppt +0.5% of value |
| Operating pH Range | 0.000 to 14.000 (+/-0.004) |
| Operating Temperature | 32 to 176º degrees F |
| Parameters Measured | Temperature, Conductivity, Resistivity, Salinity, TDS (Total Dissolved Solids), pH/mV, Oxidation Reduction Potential (ORP), Partial Pressure, Dissolved Oxygen (% and mg/L* (BOD) |
| Power | Universal power supply |
| Sampling | Yes |
| Smart Sensors / Ports | Intelligent Digital Sensors (IDS) |
| User Calibratable | Yes |
| User Replaceable | Yes |
| Warranty | 3 years |
| Waterproof | Yes |
| Part No. | Description | QTY |
|---|---|---|
| 4010-1 | single channel | 1/ea |
| 4010-2 | dual channel | 1/ea |
| 4010-3 | three channel | 1/ea |
Glucose-Glutamic Acid Solution
(Refrigeration not required)
| Part No. | Description | QTY |
|---|---|---|
| 3255-246 | APHA ST 198ppm 24x6mL Vial | 24/cs |
| 3255-486 | Apha ST 198ppm 48x6mL Vial | 48/cs |
Buffers & Solutions
| Part No. | Description |
|---|---|
| D500-699 | PHOSPHATE BUFFER 99ML |
| 5500-1 | MAGNESIUM SULFATE 2.25% W/V AQUEOUS (1L) |
| 5500-4 | MAGNESIUM SULFATE 2.25% W/V AQUEOUS (4L) |
| C250-2 | FOXPURE® CALCIUM CHLORIDE 2-HYDRATE REAGENT ACS 500G |
| 1670-1 | CALCIUM CHLORIDE 2.75% SOLUTION (1L) |
| 3100-32 | FERRIC CHLORIDE 0.025% 1 L |
| H651-3 | FOXPURE® HYDROCHLORIC ACID 36.5-38% REAGENT ACS 2.5L |
| H301-3 | FOXPURE® HYDROCHLORIC ACID INSTRAPURE 2.5L POLY BOTTLE |
| 9766-20 | WATER DISTILLED 20L |
| D500-599 | FOXBRAND BUTTERFIELDS DILUTION WATER 99ML |
| D500-590 | FOXBRAND BUTTERFIELDS DILUTION WATER 90ML |
BOD Seeds
Polyseed, an EPA accepted, commercially available
B.O.D. seed inoculum, is a broad spectrum of specialized bacteria blended specifically to be used as a seed population for the Biochemical Oxygen Demand test as conducted according to Standard Methods for the Examination of Water and Wastewater.
| Part No. | Description | QTY |
|---|---|---|
| B301-110 | PolySeed Inoculator | 50ea/BT |
| B301-210 | PolySeed NX | 50ea/BT |
Extreme Savings Opportunities
Clearance Items |
MultiLab IDS ProOBOD
The IDS ProOBOD® self-stirring optical BOD probe for use with the YSI MultiLab.
Designed to fit into standard 300 mL BOD bottles.
EPA approved for wastewater compliance reporting of BOD and CBOD.
The ProOBOD is designed for use with the MultiLab 4010-1, 4010-2, or 4010-3 instruments. Optical, luminescent technology eliminates the probe warm-up period and membrane changes. The self-stirring BOD probe has a super quiet lab stirrer that helps ensure a representative sample and improves DO response times.
· Smart sensor retains calibration in the probe
· User-replaceable, low-maintenance sensor with +1-year life
· 2-year warranty; reliable and serviceable, design reduces cost-of-ownership and reduces down-time
· Guarded sensor - the sensor guard provides protection of the sensor tip when taking the BOD probe in and out of BOD bottles
· Probe body tapered to fit into a standard 300 mL BOD bottle
· Extremely quiet operation
· No warm-up time required
· Self-stirring to provide representative sample and increase response times
300mL Disposable Biochemical Oxygen Demand
(B.O.D.) Bottles
Lightweight unbreakable and recyclable disposable bottles offer safety as well as convenience. Bottles are formed from PET resin the most easily recycled plastic available.
The use of clean new bottles eliminates the problem of contamination from sample carry over or detergent residue. Our disposable bottles have an amorphous carbon coating which keeps oxygen from diffusing into or out of your sample. Bottles provide uniform blanks high standard recoveries and quality test data.
Bottles come packaged and are consecutively numbered. Stoppers are sold separately.
227497-00 300 mL BOD Bottle, Unnumbered,
Glass Robotic Stopper
(Wheaton) BOD Bottles are ideal for incubating diluted samples of sewage, sewage effluents, polluted waters, and industrial wastes to determine the amount of oxygen required during the stabilization of the decomposable organic matter by aerobic biochemical action. We recommend the 300mL capacity bottles for the five-day BOD test as referenced in Standard Methods for the Examination of Water and Wastewater, 21st Edition, 5210B, 2005. All of the BOD bottles have large, permanently screened-on marking areas. All of the bottles are manufactured from Type I borosilicate glass. Robotic Stopper.
Polyethylene Caps
This polyethylene cap, complete with a closed cell foam insert, snaps firmly over the flared mouth of Wheaton BOD bottles. This closure prevents the evaporation of the water seal during the five-day BOD incubation period. The foam insert fits into the cap and exerts pressure on the bottle stopper to hold it securely in place.
Cap Membrane Kit
Includes bottle of electrolyte, 1 sanding disc, and 6 screw-on cap membranes. 1.00mL FEP Fluoropolymer film membranes. Black cap. Response Time (T95 - from 0 to 100%) = 18 seconds flow Dependence After 4 Minutes = 45% Required Flow Rate = 12 inches/second
Nitrification Inhibitor
Nitrification Inhibitor is used to inhibit nitrogenous oxygen demand in a BOD test.
Simply squeeze the handle one time per 300 ml sample and the perfect dosage is added to the sample.
Economical, easy to use system. Dosage instructions are printed on the reagent label as well as on top of the dispenser!
pH Strips
Indicator Sticks pH-FIX 0.0 – 14 100/pk
Recommended for pH measurement in weakly buffered or strongly alkaline solutions!
pH-Fix indicator sticks are for the rapid measurement of the pH of a water sample. Additionally they can be used for monitoring the pH of a sample during analysis to avoid errors due to weakly buffered solutions. For this purpose pH-Fix indicator sticks are clearly superior to other pH papers.In contrast to conventional indicator papers, the indicator dyes of pH-Fix sticks are chemically bonded to the cellulose fibres (DE-PS 24 36 257).
Traceable® Four-Channel Alarm Timer
The lab’s most popular timer
· Count up/down, time in/out, memories, alarm, 12/24 hour clock
· Massive ¾” high display allows viewing from across the lab
· Remarkable memory returns display to previously programmed countdown time at the touch of a button
· Extra-loud, 70 db alarms for 1 minute or can be silenced manually
· Supplied: clip, stand, magnet, battery, Traceable® Certificate
The IDS ProOBOD® self-stirring optical BOD probe for use with the YSI MultiLab.
Designed to fit into standard 300 mL BOD bottles.
EPA approved for wastewater compliance reporting of BOD and CBOD.
Click Here for Features & Specifications
The ProOBOD is designed for use with the MultiLab 4010-1, 4010-2, or 4010-3 instruments. Optical, luminescent technology eliminates the probe warm-up period and membrane changes. The self-stirring BOD probe has a super quiet lab stirrer that helps ensure a representative sample and improves DO response times.
· Smart sensor retains calibration in the probe
· User-replaceable, low-maintenance sensor with +1-year life
· 2-year warranty; reliable and serviceable, design reduces cost-of-ownership and reduces down-time
· Guarded sensor - the sensor guard provides protection of the sensor tip when taking the BOD probe in and out of BOD bottles
· Probe body tapered to fit into a standard 300 mL BOD bottle
· Extremely quiet operation
· No warm-up time required
· Self-stirring to provide representative sample and increase response times
Includes one optical sensor cap.
| Equipment used with | MultiLab Instruments |
|---|---|
| Parameters Measured | Dissolved Oxygen, Temperature |
| Part No. | Description | QTY |
|---|---|---|
| 626500 | Optical Self stirring BOD probe with temperature sensor, IDS | 1/ea |
300mL Disposable Biochemical Oxygen Demand
(B.O.D.) Bottles Lightweight unbreakable and recyclable disposable bottles offer safety as well as convenience. Bottles are formed from PET resin the most easily recycled plastic available.
The use of clean new bottles eliminates the problem of contamination from sample carry over or detergent residue. Our disposable bottles have an amorphous carbon coating which keeps oxygen from diffusing into or out of your sample. Bottles provide uniform blanks high standard recoveries and quality test data.
Bottles come packaged and are consecutively numbered. Stoppers are sold separately.
| Part No. | Description | QTY |
|---|---|---|
| D1001 | disposable, numbered 300mL | 100/cs |
227497-00 300 mL BOD Bottle, Unnumbered,
Glass Robotic Stopper(Wheaton) BOD Bottles are ideal for incubating diluted samples of sewage, sewage effluents, polluted waters, and industrial wastes to determine the amount of oxygen required during the stabilization of the decomposable organic matter by aerobic biochemical action. We recommend the 300mL capacity bottles for the five-day BOD test as referenced in Standard Methods for the Examination of Water and Wastewater, 21st Edition, 5210B, 2005. All of the BOD bottles have large, permanently screened-on marking areas. All of the bottles are manufactured from Type I borosilicate glass. Robotic Stopper.
Click Here for Specifications
| SKU | 227497-00 |
| Height (mm) | 165 |
| Diameter (mm) | 69 |
| Glass Type | Type I Borosilicate |
| Cap/ Closure Size | Stopper |
| Bottle Material | Glass |
| Bottle Style | BOD |
| Capacity (mL or oz) | 300mL or 10oz |
| Bottle Color | Clear |
| Number Sequence | Unnumbered |
| Part No. | Description | QTY |
|---|---|---|
| B300-300 | un-numbererd 300mL | 24/cs |
Polyethylene Caps
This polyethylene cap, complete with a closed cell foam insert, snaps firmly over the flared mouth of Wheaton BOD bottles. This closure prevents the evaporation of the water seal during the five-day BOD incubation period. The foam insert fits into the cap and exerts pressure on the bottle stopper to hold it securely in place.
| Part No. | Description | QTY |
|---|---|---|
| B560-273 | cap & insert for BOD btl | 50/cs |
Cap Membrane Kit
Includes bottle of electrolyte, 1 sanding disc, and 6 screw-on cap membranes. 1.00mL FEP Fluoropolymer film membranes. Black cap. Response Time (T95 - from 0 to 100%) = 18 seconds flow Dependence After 4 Minutes = 45% Required Flow Rate = 12 inches/second
| Part No. | Description | QTY |
|---|---|---|
| M590-006 | kit 1.00 mil PTFE | 1/kit |
Nitrification Inhibitor
Nitrification Inhibitor is used to inhibit nitrogenous oxygen demand in a BOD test.
Simply squeeze the handle one time per 300 ml sample and the perfect dosage is added to the sample.
Economical, easy to use system. Dosage instructions are printed on the reagent label as well as on top of the dispenser!
| Part No. | Description | QTY |
|---|---|---|
| N526-000 | Dispenser, 1vial (35 G), manual | 1/kit |
| N526-002 | 2 vials, 35 Grams each | 1/ea |
pH Strips
Indicator Sticks pH-FIX 0.0 – 14 100/pk
Recommended for pH measurement in weakly buffered or strongly alkaline solutions!
pH-Fix indicator sticks are for the rapid measurement of the pH of a water sample. Additionally they can be used for monitoring the pH of a sample during analysis to avoid errors due to weakly buffered solutions. For this purpose pH-Fix indicator sticks are clearly superior to other pH papers.In contrast to conventional indicator papers, the indicator dyes of pH-Fix sticks are chemically bonded to the cellulose fibres (DE-PS 24 36 257).
Click Here for Features & Specifications
As a result the possibility of colour bleeding, even in strongly basic solutions, is avoided. Furthermore there are the following advantages:
· Measurement of pH values is possible even in unbuffered solutions, since the sticks can be left in the solution until the final reaction color is obtanined.
· Test samples are not contaminated by the indicator dyes. Thus
solutions can be used for further investigations.
· Colors of the individual color fields cannot run into each other. This allows a more precise comparison the color scale.
· Specially developed indicator dyes guarantee a sharp differenciation between the individual pH values and a clear and easy comparison with the color scale.
Length and stability of the plastic strips protect fingers from contact with the test solution.
· Measurement of pH values is possible even in unbuffered solutions, since the sticks can be left in the solution until the final reaction color is obtanined.
· Test samples are not contaminated by the indicator dyes. Thus
solutions can be used for further investigations.
· Colors of the individual color fields cannot run into each other. This allows a more precise comparison the color scale.
· Specially developed indicator dyes guarantee a sharp differenciation between the individual pH values and a clear and easy comparison with the color scale.
Length and stability of the plastic strips protect fingers from contact with the test solution.
| Description: | pH-Fix indicator sticks |
| pH Range: | 0 - 14 |
| pack of | 100 sticks 6 x 85 mm |
| Resolution | 1.0 |
| pH Range | 0.0 - 14 |
| Part No. | Description | QTY |
|---|---|---|
| P945-101 | FOXBRAND® PH STRIPS 0-14 | 100/PK 10pks/cs |
Traceable® Four-Channel Alarm Timer
The lab’s most popular timer
· Count up/down, time in/out, memories, alarm, 12/24 hour clock
· Massive ¾” high display allows viewing from across the lab
· Remarkable memory returns display to previously programmed countdown time at the touch of a button
· Extra-loud, 70 db alarms for 1 minute or can be silenced manually
· Supplied: clip, stand, magnet, battery, Traceable® Certificate
Click Here for Description & Specification
Initiate up to four tests Simultaneously
Its microcomputer chip permits setting 4 separate channels simultaneously in any combination of countdown or count-up (stopwatch). Set any countdown time from 99 hours, 59 minutes, 59 seconds to 1 second with an accuracy of 0.01%. When zero is reached, the timer starts counting up to show time elapsed since alarming. Additional features include stopwatch, time-out, and time-of-day clock. Finger-size keys make it easy to set times and change channels.
Traceable® Certificate
An individually-numbered Traceable® Certificate provided with each unit, assures accuracy from our ISO/IEC 17025:2005 (1750.01) calibration laboratory accredited by A2LA. It indicates traceability of measurements to the SI units through NIST or other recognized national measurement institutes (NMI) that are signatories to the CIPM Mutual Recognition Agreement.
Supplied with
Spring fastener ,flip-open stand, magnet, opening for lanyard, battery, and Traceable® Certificate
Its microcomputer chip permits setting 4 separate channels simultaneously in any combination of countdown or count-up (stopwatch). Set any countdown time from 99 hours, 59 minutes, 59 seconds to 1 second with an accuracy of 0.01%. When zero is reached, the timer starts counting up to show time elapsed since alarming. Additional features include stopwatch, time-out, and time-of-day clock. Finger-size keys make it easy to set times and change channels.
Traceable® Certificate
An individually-numbered Traceable® Certificate provided with each unit, assures accuracy from our ISO/IEC 17025:2005 (1750.01) calibration laboratory accredited by A2LA. It indicates traceability of measurements to the SI units through NIST or other recognized national measurement institutes (NMI) that are signatories to the CIPM Mutual Recognition Agreement.
Supplied with
Spring fastener ,flip-open stand, magnet, opening for lanyard, battery, and Traceable® Certificate
| # Channels/zones | 4 |
|---|---|
| Timing Capacity | 99 hours, 59 minutes, 59 seconds |
| Timing Accuracy | 0.01% accuracy |
| Timing Resolution | 1 second |
| Additional Functions | time in/out, alarm, 12/24 hour clock |
| Memory | Y |
| Count Up/Count Down | count up/down |
| Dimensions | 2-3/4"x2-1/2"x1/2" |
| Weight | 2 ounces |
| A/C Plug (Y/N) | N |
| Traceable | Y |
| Supplied With | clip, stand, magnet, battery, Traceable® Certificate |
| Part No. | Description | QTY |
|---|---|---|
| 5004 | Four Channel, alarm timer | 1/ea |
