Advanced GC Column Technology.

SGE offers a comprehensive GC capillary column range for almost any chromatographic application,providing the best possible combination of Performance, Robustness, Reproducibility, Low Bleed and Inertness. Advanced technology ensures brilliant results every time.

The full range of SGE GC capillary columns are available from Fox Scientific, Inc. This is only a sample of the columns that can be purchased. If you have need of others please contact Fox Scientific at 800-369-5524.



100% Dimethyl Polysiloxane

BP1

An industry standard non-polar phase suitable for all routine analyses.

ID (mm)	Film Thickness (μm)	Max Temp °C	Available Lengths (m)	Item #s
0.1	0.1	-60 to 340/360	10	054022
0.25	0.1	-60 to 340/360	15	054039
0.22	0.1	-60 to 340/360	12, 25	054040, 054041
0.25	0.25	-60 to 340/360	15, 30, 60	054043, 054044, 054045
0.22	0.25	-60 to 340/360	12, 15, 25, 50, 60	054046, 054047, 054048, 054050, 054051
0.22	1	-60 to 340/360	25, 50	054053, 054054
0.25	1	-60 to 340/360	30	054056
0.32	0.25	-60 to 340/360	15, 30, 50	054059, 054061, 054062
0.32	0.5	-60 to 340/360	12, 25, 50	054064, 054065, 054066
0.32	0.5	-60 to 340/360	30, 60	054068, 054069
0.32	1	-60 to 340/360	12, 25, 50	054070, 054071, 054072
0.32	3	-60 to 300/320	30	054073
0.32	5	-60 to 280/300	50, 60	054082, 054085
0.53	1	-60 to 340/360	12, 15, 50	054086, 054087, 054090
0.53	0.5	-60 to 340/360	30	054092
0.53	5	-60 to 280/300	25, 50	054095, 054096





BPX1

100% Dimethyl Polysiloxane

• Non-polar column
• Dimensionally stabilized phase
• Low bleed
• Specifically designed for high temperature hydrocarbon analysis
• Ideal for simulated distillation

Polyimide Clad

ID (mm)	Film Thickness (μm)	Max Temp °C	Available Lengths (m)	Item #s
0.1	0.1	-30 to 400/400	10	054777
0.53	0.9	-30 to 400/400	10	054801
0.53	2.65	-30 to 370/370	6, 10	054802, 0548025
0.53	0.1	-30 to 400/400	10	054803

5% Phenyl Methylpolysiloxane

BP5

5% Phenyl / 95% Dimethyl Polysiloxane

• Excellent general purpose GC column
• Low bleed
• Non-polar
• High temperature

Application Areas: Aromatics, pesticides, herbicides, drugs of abuse, hydrocarbons, GC/MS applications

Suitable replacement for: DB-5, Rtx-5, HP-5, Ultra-2, PTE-5, SPB-5, MDN-5, CP-Sil 8CB, VB-5, ZB-5

ID (mm)	Film Thickness (μm)	Max Temp °C	Available Lengths (m)	Item #s
0.22	0.25	-60 to 320/340	12, 25	054167, 054168
0.32	0.25	-60 to 320/340	15, 25, 60	054177, 054178, 054180
0.25	0.25	-60 to 320/340	15, 30, 60	054182, 054183, 054184
0.32	0.5	-60 to 320/340	25	054186
0.32	1	-60 to 320/340	25, 30	054188, 054189
0.53	1	-60 to 320/340	15, 30	054195, 054198
0.53	5	-60 to 280/300	30	054196
0.53	1.5	-60 to 320/340	15	054199
0.25	1	-60 to 320/340	30	054203
0.32	0.5	-60 to 320/340	30	054216



BP5MS

Available Now - the New BP5MS optimized silphenylene column Optimized Silphenylene content for general purpose MS analyses. Perfect for your 5% MS analysis. Non polar, 5% equivalence. Low bleed, great inertness.

5% Phenyl Polysilphenylene-siloxane

• High temperature
• General Purpose GC column - suitable for over 80% of all routine analyses performed by gas chromatography
• Very Low Bleed - ideal for trace analysis
• Non-Polar Extremely inert
• Ideal for GC-MS

Application Areas: Ultra trace analyses, pesticides/herbicides, hydrocarbons, solvents, phenols, amines, GC/MS and other specific detector applications

Suitable Replacement for: DB-5ms, ZB-5ms, Rxi-5Sil MS, VF-5ms, CP-Sil 8 CB

ID (mm)	Film Thickness (μm)	Max Temp °C	Available Lengths (m)	Item #s
0.18	0.18	-40 to 330/350	20	054301
0.25	0.25	-40 to 330/350	15, 30	054308, 054310



Cyanopropylphenyl Polysiloxane

BPX-VOLATILES

• Polar phase
• EPA volatile organics analysis (EPA 624, 502.2, SW-846 8240/8260)

Application Areas: Environmental analyses, volatile organics, alcohol analysis, USP G43

Suitable Replacement for: DB-VRX, HP-624, OPTIMA 624, ELITE-624, 007-624, RTX-VOLATILES, SPB-624, TRV1, CPSIL 13 CB, VOCOL, VB-624, CP-624

ID (mm)	Film Thickness (μm)	Max Temp °C	Available Lengths (m)	Item #s
0.25	1.4	0 to 290/300	30, 60	054980, 054981
0.32	1.8	0 to 290/300	30, 60	054983, 054984
0.53	3	0 to 290/300	30, 60	054984, 054985

Polyethylene Glycol

BP20 (Wax)

• Industry standard wax column
• Polar phase
• Cross-linked for stability and washing

Application Areas: alcohol, free acids, fatty acid methyl esters, aromatics, solvents, essential oils

Suitable Replacement for: DB-Wax, HP-20M, Supelcowax 10, CB-Wax, Stabilwax, Carbowax, HP-Innowax, Rtx-WAX, PE-WAX, RH-WAX, ZB-WAX, TRWAX

ID (mm)	Film Thickness (μm)	Max Temp °C	Available Lengths (m)	Items #s
0.1	0.1	20 to 260/280	10	054405
0.25	0.5	20 to 260/280	30, 60	054415, 054458
0.22	0.25	20 to 260/280	25, 30, 50, 60	054421, 054424, 054422,054425
0.25	0.25	20 to 260/280	30, 60	054427, 054428
0.32	0.25	20 to 260/280	30, 50, 60	054433, 054431, 054434
0.32	0.5	20 to 260/280	25, 30, 50, 60	054436, 054438, 054437, 054457
0.25	1	30 to 240/260	30	054439
0.53	0.5	20 to 260/280	30	054440
0.32	1	20 to 240/260	25, 50, 60	054442, 054443, 054445
0.32	1	30 to 240/260	30	054444
0.53	1	20 to 240/260	15, 25, 30, 60	054450, 054448, 054451, 0544515
0.53	2	30 to 240/260	25	054456





50% Phenyl Polysilphenylene-siloxane

BPX50

• Mid polarity
• Inert
• Low bleed
• High temperature
• Ideal for a range of EPA methods and pharmaceutical applications

Application Areas: EPA methods 604, 608, 8060, 8081, triazines/herbicides, drug screening, steroids and a variety of pharmaceutical applications

Suitable Replacement for: OV-17, SP-2250, DB-17, DB-17ms, DB-17ht, Rtx-50, SPB-50, HP-50+, HP-17



ID (mm)	Film Thickness (μm)	Max Temp °C	Available Lengths (m)	Items #s
0.1	0.1	80 to 330/350	10	054740
0.18	0.18	80 to 330/350	20	054742
0.25	0.25	80 to 330/350	30	054751
0.25	0.25	80 to 330/350	60	054752

---
